Model box point - Select a point on the model bounding box for the triad origin.ĬNC machine contouring motion is controlled using line G1 and arc G2 G3 commands.Stock box point - Select a point on the stock bounding box for the triad origin.Selected point - Select a vertex or an edge for the triad origin.Model origin - Uses the coordinate system (WCS) origin of the current part for the tool origin.Setup WCS origin - Uses the workpiece coordinate system (WCS) origin of the current setup for the tool origin.The Origin drop-down menu offers the following options for locating the triad origin: Use this if your model does not contain a suitable point & plane for your operation. This uses both the origin and orientation of the existing coordinate system. Select coordinate system - Sets a specific tool orientation for this operation from a defined user coordinate system in the model.Both the X and Y axes can be flipped 180 degrees.

Select X & Y axes - Select a face or an edge to define the X axis and another face or edge to define the Y axis.Both the Z and Y axes can be flipped 180 degrees. Select Z axis/plane & Y axis - Select a face or an edge to define the Z axis and another face or edge to define the Y axis.Both the Z and X axes can be flipped 180 degrees. Select Z axis/plane & X axis - Select a face or an edge to define the Z axis and another face or edge to define the X axis.Model orientation - Uses the coordinate system (WCS) of the current part for the tool orientation.

Setup WCS orientation - Uses the workpiece coordinate system (WCS) of the current setup for the tool orientation.The Orientation drop-down menu provides the following options to set the orientation of the X, Y, and Z triad axes:

SequenceNumber = quenceNumberStart Įrror(localize("Program name must be a number.Specifies how the tool orientation is determined using a combination of triad orientation and origin options. Könnt ihr mir auch sagen wie zur Hölle ich das ganze in dem Postprozessor einbauen soll? =) Schon mal Danke für die schnellen Antworten.
